Interrupted Serrations Welded Steel Grating Steel Structure Platform Plate

​Introduction of Road Steel grating:

Road steel grating is generally made of carbon steel, hot dip galvanizing, can play a role in preventing oxidation. It can also be made of stainless steel. Steel grid plate has ventilation, lighting, heat dissipation, anti-skid, explosion-proof and other properties.

Road Steel grating is a type of steel grating specifically designed for use in roadways, pedestrian paths, and other transportation-related applications.




Interrupted Serrations Welded Steel Grating Steel Structure Platform Plate



Specification of road steel grating:

Flat steel spacing 30,40,60mm, twisted square steel spacing 50,100mm, flat steel width 20-60mm, flat steel thickness 3,4,5mm, twisted square steel (twist steel) specification: 5 * 5mm, 6 * 6mm, 8 * 8mm.




Interrupted Serrations Welded Steel Grating Steel Structure Platform Plate



Specifications of steel grating plate
Bearing bar20x5,25x3,25x4, 25x5,30x3,30x4,30x5,32x3,32x5,40x5,50...75x8mm, etc.
Bearing bar depth25,30,30.16,32.5,34.3,40,50,60,62,65mm, etc.
Cross bar5x5, 6x6,8x8mm (twisted bar or round bar)
Cross bar spacing40, 50,60,65,76,100,101.6,120,130mm or as customers' requirement.
Flat bar typePlain, Serrated (tooth-like), l bar (l section)
Surface treatmentUntreated
Hot dip galvanized
Cold dip galvanized
PVC coated
Powder coated



Evercross Steel Bridges Overview :



EVERCROSS STEEL BRIDGE SPECIFICATION
EVERCROSS
STEEL BRIDGE		Bailey bridge(Compact-200, Compact-100, LSB, PB100, China-321,BSB)
Modular bridge( GWD, Delta, 450-type,etc),
Truss Bridge,Warren bridge,
Arch bridge, Plate bridge,Beam bridge,Box girder bridge,
Suspension bridge,Cable-stayed bridge,
Floating bridge,etc
DESIGN SPANS10M TO 300M Single span
CARRIAGE WAYSINGLE LANE, DOUBLE LANES,MULTILANE,WALKWAY,ETC
LOADING CAPACITYAASHTO HL93.HS15-44,HS20-44,HS25-44,
BS5400 HA+20HB,HA+30HB,
AS5100 Truck-T44,
IRC 70R Class A/B,
NATO STANAG MLC80/MLC110.
Truck-60T,Trailer-80/100Ton,etc
STEEL GRADEEN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C
AS/NZS3678/3679/1163/Grade 350,
ASTM A572/A572M GR50/GR65
GB1591 GB355B/C/D/460C,etc
CERTIFICATESISO9001, ISO14001,ISO45001,EN1090,CIDB,COC,PVOC,SONCAP,etc
WELDINGAWS D1.1/AWS D1.5
AS/NZS 1554 or equivalent
BOLTSISO898,AS/NZS1252,BS3692 or equivalent
GALVANIZATION CODEISO1461
AS/NZS 4680
ASTM-A123,
BS1706
or equivalent




Application of road steel grating :

They are widely used in steel structure platforms, stair treads, sidewalks, drainages and well covers etc. We can design and manufacture standard steel grating and in customized shapes per client's requirements.





Features of road steel grating:

The light structure is advantageous for hoisting.
The hot dipping zinc surface treatment offers good corrosion resistance.

The reliable grid welding enables high load bearing.

Available in various sizes, load capacities, and designs to meet specific needs.
Corrosion Resistance.



Interrupted Serrations Welded Steel Grating Steel Structure Platform Plate


Advantages of road steel grating :

Easy Installation
Lightweight and modular design allows for quick installation and replacement.

Common Uses
Drainage Grates: Integrated into roadways to facilitate water runoff.

Crosswalks: Used in pedestrian paths to enhance safety and accessibility.
Inspection Covers: Provides access points for utilities below road surfaces.
